ARS Series Sensors Constructed With High Temperature Materials For Long Term Operation
-
SensortypeAnalog Output Position Sensors
-
MountingtypeFlange Mount
-
Operatingtemperaturerange-40°C To 85°C
-
Resolution0.01 Mm
-
Responsetime1 Ms
-
Measurementrange0 To 100 Mm
-
ProtectionratingIP67
-
OutputsignalAnalog Voltage
-
Accuracy±0.5%
-
Place of OriginChina
-
Brand NameARS Series Sensors
ARS Series Sensors Constructed With High Temperature Materials For Long Term Operation
Structural Features:
● Employs PT100B platinum resistance thermometer, withstanding temperatures up to 400℃.
● High-temperature resistant glass fiber braided wire, capable of long-term operation at 350℃.
● 3mm diameter stainless steel housing, extremely small sensor size, allowing for installation in confined spaces.
● The sensor head is entirely made of high-temperature materials, ensuring stable long-term operation at 350℃.
● Low heat capacity, rapid heat transfer, and short thermal response time.
Applications:
● Specifically developed for 3D printers. Supports high-temperature 3D material printing.
● High-precision PT100 temperature sensing element, providing support for precise temperature control in 3D printing.
● Also suitable for other applications requiring rapid thermal response, confined spaces, and high temperatures.
● Non-sealed structure, not suitable for excessively humid environments.
